HT-HZFS
Stainless Steel Horizontal Filters
Hidrotermal’s bobbin-wound fiberglass filters are one of the most popular in the industry, offering crystal clear waters and outstanding performance. Safe for Users and the Environment, UV-Resistant Finish & AntiCorrosive our filters work well in direct sunlight for years of prolonged operation.
| MODEL | FILTER AREA | RATED FLOW | Filter Media (KG) | Dimensions (mm) | Flange Size | ||||
|---|---|---|---|---|---|---|---|---|---|
| M3/H | GPM | Sand | Gravel | Tank Height | Tank Diameter | Tank Length | |||
| HT-HZFS1225 | 2.65m2 | 108 | 475.52 | 1750 | 700 | 1390 | 1200 | 2500 | 3" /90mm |
| HT-HZFS1230 | 3.21m2 | 130 | 572.39 | 2330 | 925 | 1390 | 1200 | 3000 | 3" /90mm |
| HT-HZFS1240 | 4.33m2 | 173 | 761.72 | 2800 | 1120 | 1390 | 1200 | 4000 | 4" /110mm |
| HT-HZFS1250 | 5.45m2 | 218 | 959.85 | 3500 | 1400 | 1390 | 1200 | 5000 | 4" /110mm |
| HT-HZFS1425 | 3.02m2 | 126 | 554.78 | 2750 | 880 | 1830 | 1400 | 2500 | 4" /110mm |
| HT-HZFS1430 | 3.67m2 | 150 | 660.45 | 3375 | 1000 | 1830 | 1400 | 3000 | 4" /110mm |
| HT-HZFS1440 | 4.97m2 | 198 | 871.79 | 4400 | 1400 | 1830 | 1400 | 4000 | 6" /160mm |
| HT-HZFS1450 | 6.27m2 | 250 | 1100.79 | 5500 | 1760 | 1830 | 1400 | 5000 | 6" /160mm |
| HT-HZFS1625 | 3.52m2 | 144 | 634.03 | 3800 | 850 | 2220 | 1600 | 2500 | 6" /160mm |
| HT-HZFS1630 | 4.32m2 | 172 | 757.32 | 4700 | 1050 | 2220 | 1600 | 3000 | 6" /160mm |
| HT-HZFS1640 | 5.92m2 | 237 | 1043.51 | 6080 | 1360 | 2220 | 1600 | 4000 | 6" /160mm |
| HT-HZFS1650 | 7.52m2 | 300 | 1320.90 | 7600 | 1700 | 2220 | 1600 | 5000 | 6" /160mm |
caracteristicas
- Constructed from high-grade stainless steel for superior durability.
- Double diffuser layer with ABS laterals and Nozzle plate.
- Large manhole openings for easy maintenance.
- Multiple valve configurations for flexible operation.
- Heavy-duty flanged connections for secure installation
- High filtration capacity for large-scale commercial applications
Condiciones de trabajo
- Max. Operating Water Temperature: ≤50°C/122ºF
- Max. Working Pressure: 58psi/4.0bar
accesorios
Top mounted Six-Way Valve
Standard Plastic Clamp or Optional Stainless Steel Clamp
Distributor
